DESCRIPTION

Basic Info

Model NO.	sma connector
Application	RF, PCB, Audio & Video, Microwave
Type	SMA Connector
Plating	Gold Plating
Certification	ISO9001, CE, ISO, RoHS
Gender	Female Male
Fastening Type	Clamp, Crimp, Solder, Through Hole, Twist on
Mounting Type	PCB Mount / Panel Mount / Cable
Insulating Materials	Teflon White
Contact Finish	Gold Plating / Nickel Plating
Materials	Cooper / Steel
Standard	SMA Connector
Product Name	SMA Connector
Orientation	Straight / Right Angle
Impedance	50Ω
Mounting Feature	Flange / Bulkhead / Through Hole / SMT / Offset Ty
Body Material	Copper / Steel
Body Plating	Gold Plating / Nickel Plating
Function	Waterproof / Dustproof / Other
Polarity	Standard / Reverse Pole
Certificate	CE/ISO9001/RoHS
Transport Package	Box
Specification	OEM / ODM
Trademark	RENHOTEC
Origin	Dongguan
Production Capacity	1000000 Piece/Pieces / Month

Product Description

Welcome to Renhotec Group Ltd! Our Slogan is Make Connection Easier...Product Description

Full Series : RF Connector

All types of RF Connector from OEM Manufacturer in China

The SMA connector is a semi-precision sub-miniature RF and microwave connector that is extensively used, especially for RF connections within electronic systems for frequencies up to 18 GHz and sometimes more. Although now well established, the SMA connector is likely to see its use extended as many new RF systems see their operating frequencies extending well into the microwave region.Features:-Light weight, compact and anti-vibration design for harsh environments-Available in brass and stainless steel with gold, nickel and passivated plating-Terminates to all standard flexible coaxial cables, as semi-rigid and conformable cables-Subminiature design: Space-saving vertical mating

Gender	Plug / Socket
Orientation	Straight / Right Angle
Polarity	Standard / Reverse Pole
Impedence	50Ω
Frequency	0-6GHZ, 0-12GHZ, 0-18GHZ
Voltage Rating	335 Volts RMS Continuous
VSWR	1000 VRMS Min
Body Material	Brass/Gold Plated, Steel/ Passivated
Insulators	PTFE
Contact Pin	Brass/Gold Plated
Nut	Brass/ Nickel plated
Temperature Range	-65°C to +165°C
Durability (matings)	≥ 500 (cycles)

Application

-Aerospace and Defense: Hand-held field Device and Instrumentation-Medical: Instrumentation-Commercial Vehicle: GPS-Telecommunications: Antenna,Wireless Base Stations, Cellular Mobile System-Data/Communications: Wifi, WiMAX-Industrial: Active and passive components, instrumentation, M2M Communications, Vehicle Tracking -System

Certifications Company Profile
Renhotec Hardware ElectronicsRENHOTEC is a full-service leading global supplier of a wide variety of standard and custom RF coaxial connectors, cable assemblies and unique solutions for today's cutting edge applications. RENHOTEC is fully committed to meeting the needs of our customers, we offer a wide range of RF connector interface types and are able to produce custom products for specific applications. Our team is always focused on designing, developing and taking pride in custom innovative solutions to meet our customers' needs. - Acquired ISO9001, ISO14001, QC080000 and TS16949 certification.- All items are in line with EU ROHS and REACH environmental requirements.- Markets supported include automotive, medical, instrumentation, telecom and wireless etc.

Our AdvantagesCustomized DesignProfessional engineer team help you with drawing design and provide you suggestions based on your special electrical and environmental performance requirements.Technology ImprovementEstablish and optimize the process of the production line. Continuous improvement to make sure the targeted quality and yield achieved and maintainQuality Inspection CenterWith professional inspection center to test the electrical, mechanical and environmental performance and ensure the high quality.FAQ

Q :How can I get a sample to check your quality?A : Free sample is available.

Q :What is your term of delivery?A : Usually, we use EXW. As well, FOB, CIF and DDP are all available. Others can be netotiatable.
Q :When can I get the price?A : All the quotaitons can be handled within 6-12 hours.
Q: Could you accept custom products?
A: Yes, Any custom design can be offered.
Q :What about the lead time for the mass production?A :Honestly, it depends on the order quantity and the season you place the order. Normally, it is about 20-25 days for qty around 50K.
