DESCRIPTION

Basic Info

Model NO.	SMA Connector
Mounting Type	Through Hole
Insulating Materials	Teflon/Plastic
Contact Finish	Gold
Materials	Brass
Standard	SMA Connector
Frenquency Range	DC-7.5GHz
Durability	≥500(Cycles)
Working Voltage	≥100mΩ
Impedance	50Ω
Transport Package	PE Bag/Carton Box
Specification	CE\RoHS\SGS\ISO9001/YUV
Trademark	RISINGSUN OR OEM
Origin	China
HS Code	8536909000
Production Capacity	100000PCS/Month

Product Description

RISINGSUN focus on RF coaxial cable assembly (7/16DIN/N/TNC/BNC/FME/U.FL/IPEX/L9/SMA/SMB/MMCX/MCX/OEM) RF cable assemblies in 50 ohms can be ordered using the following connector types such as 7/16 DIN, BNC, FME, MCX, MMCX, N, QMA, SMA, SMB, SMC, SMP, SSMB, TNC, UHF, U.FL and 75 ohms cable assemblies can be made with the following 75 ohms connectors such as BNC, F, N, SMB, SMC, TNC and mini SMB RF cable assemblies includes: RG141/RG142/RG174/ RG178/RG179/RG180/ RG187/RG196/RG213/RG214/RG218/RG219/ RG223/RG303/RG316/RG316-DS/RG393/RG400/RG401/RG402/RG405/RG58/URF cable assemblies can be produced with many different connector types and custom lengths depending on your needs and applicationsIf you require a special RF cable assembly configuration not found here, you can create your own RF cable assembly configuration by calling our sales department

Temperature range	-65~+165°C (PE Cable -40~+85°C)
Vibration	MIL-STD-202,Method 213
Impedance	50 OHM
Frequency Range	DC - 12.4GHz(0-18GHz)
Working Voltage	335V max
Withstand Voltage	1000V rms
Center Contact	≤ 3 mΩ
Outer Contact	≤2mΩ
Insulation resistance	≥5000M OHM
Insertion loss	≤0.15 dB/6GHz
Durability (mating)	≥500 (cycles)
Insertion loss	0.15dB (7.5GHz max)
VSWR	Straight Soft cable ≤1.10+0.002f Semi-steel cable≤1.05+0.001f Right angle Soft cable ≤1.20+0.003f Semi-steel cable≤1.10+0.001f

Material & Plating

Body	Brass	Nickel plated / Alloy plated
Inner Pin	Brass	Gold plated
Resilient Contact	Beryllium Copper	Gold plated
Socket Contact	Beryllium or tin bronze	Gold plated
Insulator	PTFE
Crimp Ferrule	Copper alloy	Nickel / Gold plated
O-ring sealing	Silicone Rubber

APPLICABLE STANDARDMIL-C-39012;CECC 22110;IEC 60169-15.Our Service: 1) Quick Response --All inquiries will be replied within 24 hours. 2) Professional Quotation --All prices will be quote according to customers' detailed specifications & requirements. 3) OEM & ODM Service 4) Can print your own brand on the jacket printing with foot or meter marking. 5) Make customized designs for stickers, drums, outer cartons, etc. 6) Stable Quality --All materials and products passed restrict QC procedures,comply with international standards. 7) Fast Delivery --LCL orders,15days after confirmation; FCL orders, 20 days after Confirmation in usual. Good After-sales Service --We chose the fastest vessel to POD for delivery our goods to clients,--All Documents will be issued according to clients' instructions, to save troubles from local customs.--Any complaint to quality or packing issued will be responded, and terminated with proper solutions for clients.
