1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

Overview Product Description Coaxial fixed dummy load absorb RF/Microwave energy and are commonly used as dummy loads of

Send your inquiry

DESCRIPTION

Basic Info
Model NO. UIYCT1500A
Type Telecommunication
Support Network 3G/4G/5G/6G
Information content telecommunication signals
Certification ISO, RoHS
Condition New
Freq. Range DC~3GHz
Power(W) 1500W
Payment Term T/T, Paypal, Alipay
VSWR Max 1.25
Impedance 50 ohm
Dimension 400 x 410 x 147mm
Cerfiticates RoHS, REACH, ISO9001, ISO14001
Connector Type 7/16
Transport Package Gift Box
Specification metal
Trademark UIY
Origin China
HS Code 8548000002
Production Capacity 10000PCS/Month
Product Description

Coaxial fixed dummy load absorb RF/Microwave energy and are commonly used as dummy loads of antenna and transmitter.

They are used as match ports in many multiport microwave device such as circulator and directional coupler to make these ports which are not involved in the measurement be terminated in the characteristic impedance in order to ensure an accurate measurement.Detailed Photos

1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load

Description1500W RF Termination DC-3GHz 50ohm RF Terminator RF Dummy Load
Model NumberUIYCT1500A
Frequency RangeDC~3GHz
Power1500W
VSWR Max1.25
Connector Type7/16-M, 7/16-F
Impedance50 Ω
Dimension400 × 410 × 147mm
WarrantyOne Year
CerfiticatesRoHS, REACH, ISO9001, ISO14001
CertificationsPackaging & ShippingCompany ProfileOur Advantages

Since 2003, UIY Inc. has become a critical supplier and partner to major companies serving the Aerospace, Radar, Defense, Medical, Communications and Specialty Test industries.UIY's product offerings include: RF Isolator, RF CirculatorCoaxial Termination, Coaxial AttenuatorRF Filters, Duplexer, Triplexer Power Divider/Splitter, RF Combiner/Hybrid CouplerDirectional CouplerTX RX Combiner/Splitter/Multi couplerWaveguide to Coaxial Adapter, etc.We offer cost-effective customized solutions in a wide range of RF and Microwave Components and Subsystems.Advantages:we offer - ROHS Compliantwe offer - HFSS Simulationwe guarantee - One Year warrantywe guarantee - Fast Delivery we support - OEM & Contract Manufacturing

FAQ

Q. Are you a factory or trading company?
A: We are a factory and we have over 20 years of experience focusing on manufacturing .We can give you competitive price and professional service.Q. Do you have any certificates?
A: Yes, we have ISO, REACH, RoHS certificates.Q. Would you make custom products?
A: Yes, we offer customized service per your requirements.Q. What about lead time for sample and production?
A: It's about 2 weeks for new design sample and 1~4 weeks for production. It depends on the order quantity.Q. What is the Terms of Payment?
A: T/T, Paypal, Alipay

Q. How long is the warranty ?
A: One year
